Quantum Scalar 1000 - Figure 5-199 Keep Learned Offsets Dialog; Figure 5-200 Confirmation Screen

Service Menu 5-141
22 June 2004
If Y is selected for the Continue parameter value,
the Keep Learned Offsets Dialog (Figure 5-199 on page
5-141).
Figure 5-199 Keep Learned Offsets Dialog
Parameter Value
Keep offsets? Y to keep learned offsets
N to reject keeping learned
offsets. N is the default setting.
If Y is selected for the Keep offsets parameter value, the
Conformation Screen (Figure 5-200 on page 5-141)
appears.
If N is selected, the Progress Screen (Figure 5-201 on
page 5-142) appears.
Figure 5-200 Confirmation Screen
Parameter Value
Confirm Y to confirm keeping learned
offsets
N to reject keeping learned
offsets. N is the default setting.
If Y is selected for the Confirm parameter value,
the Starting and Ending Dialog (Figure 5-201 on page
5-142) appears.
Learned offsets can
be preserved after
teach completes.
Keep offsets?: N
Keeping learned
offsets may cause
positioning errors.
Confirm: N
