5-64 Menus and Commands
6-00054-02 Rev A
Type Indicates the cartridge media
type (SDLT I, DLTIII,
DLTIIIXT, DLT IV, 3480,
3490E, 3590, 3590 DL, NCTP,
AIT, LTO1, LTO2).
Home Indicates the home location of
the cartridge.
Current Indicates the current location
of the cartridge.
Element Dialog
Path: Main Menu Database Menu Element Dialog
Use the Element Dialog to select specific element
information from the database. See Figure 5-89.
Figure 5-89 Element Dialog
Parameter Value
Coord The first field indicates the
type of cell (I for I/E Station, D
for Drive, S for Storage cell).
The second field displays
module numbers that can be
modified if EMs are present
(1–4).
The third field indicates the
storage cell section (1–4), drive
bay (1–2), or IE station
number.
The fourth field indicates the
column of the section (A–E),
drive port (A–B), or IE station
column.
Enter Desired
Coord: I 01 1 A< 12
OR Element: 01193
Accept: N
