Quantum Scalar 1000 User Manual

5-76 Menus and Commands
6-00054-02 Rev A
Ports Dialog
Path: Main Menu Setup Menu Library
Submenu SCSI Submenu Ports Dialog
Use the Ports Dialog to view the current SCSI bus type
and usage. See Figure 5-103.
Figure 5-103 Ports Screen
Parameter Value
Bus 0 : INSTALLED YES indicates the port is
installed.
NO indicates the port is Not
installed.
Bus 0 : TYPE HVD indicates the bus is high
voltage differential.
LVD indicates the bus is low
voltage differential.
SE indicates the bus is single
ended.
Bus 1 : INSTALLED YES indicates the port is
installed.
NO indicates the port is Not
installed.
Bus 1 : TYPE HVD indicates the bus is high
voltage differential.
LVD indicates the bus is low
voltage differential.
SE indicates the bus is single
ended.
INSTALLED TYPE
Bus 0: YES HVD
Bus 1: NO -
