Quantum Scalar 1000 - Figure 5-48 Response Screen; Figure 5-49 Response Screen; Figure 5-50 Warning Dialog

Commands Menu 5-41
22 June 2004
If Y is selected for the Accept parameter value, the
Response Screens appear. See Figure 5-48 on page 5-41
and Figure 5-49 on page 5-41. Otherwise, the changed
parameters continue to display but no action is taken.
Figure 5-48 Response Screen
The Accessor moves the cartridge between the selected
Source and Target elements.
Figure 5-49 Response Screen
If a Move Media is attempted without an inventory, the
following screen appears. See Figure 5-50.
Figure 5-50 Warning Dialog
Parameter Value
Continue Y to continue
N to return to the previous
menu
If Y is selected for the Continue parameter, the Warning
message is removed.
Requested command is
now in progress ...
Requested command is
now complete.
-=> WARNING <=-
The library may not
be inventoried.
Continue : N
