5-110 Menus and Commands
6-00054-02 Rev A
Unload Drives Dialog
Path: Main Menu Utils Menu Drives
Submenu Unload Drives Dialog
Use the Unload Drives dialog to eject a tape from the
specified drive. See Figure 5-147.
Figure 5-147 Unload Drives Dialog
Parameter Value
Coord The first field indicates the
type of cell (I for I/E Station, D
for Drive, S for Storage cell).
The second field displays
module numbers that can be
modified if EMs are present
(1–4).
The third field indicates the
storage cell section (1–4), drive
bay (1–2), or IE station
number.
The fourth field indicates the
column of the section (A–E),
drive port (A–B), or IE station
column.
The fifth field indicates the
row of the column.
(01–12 for ½-inch and SDLT/
DLT coordinates)
(01–14 for LTO coordinates)
(01–18 for AIT coordinates)
Element Displays the element number
that corresponds to the
coordinate parameter.
Accept Y to accept changes
N to reject changes
Enter SOURCE
Coord: D 01< 1 A 01
OR Element: 01200
Accept: N
