Service Menu 5-137
22 June 2004
If Y is selected for the Cancel parameter value, the test is
cancelled. Otherwise, the test continues.
PowerSup Dialog
Path: Main Menu Service Menu Diags
Submenu PowerSup Dialog
Use the PowerSup Dialog to display the installed dual
power supplies. See Figure 5-189.
This screen shows installed DC power supply status with
respect to AC input and DC output, indicating whether the
power supplies are functioning properly.
If dual power supplies are not installed, the Function Not
Available Screen appears. See Figure 5-190.
Figure 5-189 Power Supply Screen
Figure 5-190 Function Not Available Screen
1. 24V DC: Y AC: Y
1. 48V DC: Y AC: Y
2. 24V DC: Y AC: Y
2. 48V DC: Y AC: Y
This function is not yet
available. Press Escape
To Next Page
