Cartridge Accessor
The Cartridge Accessor identifies and moves cartridges
between the storage cells, tape drives, and the Insert/Eject
Station. See Figure 2-3.
Figure 2-3 Cartridge Accessor
Top X-Rail Assembly
Y-Axis Assembly
Gripper Assembly
Bottom X-Rail Assembly
