Service Menu 5-123
22 June 2004
The third field indicates the
storage cell section (1–4), drive
bay (1–2), or IE station number.
The fourth field indicates the
column of the section (A–E),
drive port (A–B), or IE station
column.
The fifth field indicates the row
of the column.
(01–12 for ½-inch and SDLT/
DLT coordinates)
(01–14 for LTO coordinates)
(01–18 for AIT coordinates)
Element Displays the element number
that corresponds to the
coordinate parameter.
Accept Y to accept changes
N to reject changes
If Y is selected for the Accept parameter value, the
Number of Elements Dialog appears.
See Figure 5-170. Otherwise, the changed parameters
continue to display but no action is taken.
Figure 5-170 Number of Elements Dialog
Parameter Value
Get/Put Selects the number of elements
where get/put operations are
applied (0000–1200)
Accept Y to accept changes
N to reject changes
Number of Elements
to Get/Put : 0100
Accept : N
