5-44 Menus and Commands
6-00054-02 Rev A
If Y is selected for the Accept parameter value, the
Number of Elements Dialog appears. See Figure 5-53.
Otherwise, the changed parameters continue to display
but no action is taken.
Figure 5-53 Number of Elements Dialog
Parameter Value
Elements Indicates the number of
elements to inventory
Accept Y to accept changes
N to reject changes
If Y is selected for the Accept parameter value, the
Response Screens appear. See Figure 5-54 and
Figure 5-55. Otherwise, the changed parameters
continue to display but no action is taken.
Figure 5-54 Response Screen
The barcode scanner inventories the specified storage
cells.
Figure 5-55 Response Screen
Parameter Value
Found Indicates the total number of
cartridges detected
Number of Elements
to Inventory: 0100<
Accept: N
Requested command is
now in progress ...
Requested command is
now complete.
Found : 100
