Parameters:
<LimitLinePoints> Variable number of level values.
Note that the number of vertical values has to be the same as
the number of horizontal values set with CALCulate<n>:
LIMit<li>:CONTrol[:DATA]. If not, the R&S FSV/A either
adds missing values or ignores surplus values.
The unit depends on CALCulate<n>:LIMit<li>:UNIT
on page 1049.
*RST: Limit line state is OFF
Default unit: DBM
Manual operation: See " Data Points " on page 479
CALCulate<n>:LIMit<li>:UPPer:MARGin
<Margin>
This command defines an area around an upper limit line where limit check violations
are still tolerated.
Suffix:
<n>
.
irrelevant
<li> Limit line
Parameters:
<Margin> numeric value
*RST: 0
Default unit: dB
Manual operation: See " Margin " on page 479
CALCulate<n>:LIMit<li>:UPPer:MODE <Mode>
This command selects the vertical limit line scaling.
Suffix:
<n>
.
Window
<li> Limit line
Parameters:
<Mode> ABSolute
Limit line is defined by absolute physical values.
The unit is variable.
RELative
Limit line is defined by relative values related to the reference
level (dB).
*RST: ABSolute
Manual operation: See " X-Axis " on page 479
CALCulate<n>:LIMit<li>:UPPer:OFFSet <Offset>
This command defines an offset for a complete upper limit line.
