Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
1110User Manual 1178.8520.02 ─ 01
Suffix:
<sli>
.
1..n
Index in Touchstone file list
Use [SENSe:]CORRection:FRESponse:USER:
SLISt<sli>:SIZE? to determine the maximum index number.
<spi> 1..4
S-port pair index, where:
1 = From port - from port
2 = To port - from port
3 = From port - to port
4 = To port - to port
Example:
SENS:CORR:FRES:USER:SLIS2:SEL 'FRes21.s2p'
SENS:CORR:FRES:USER:SLIS2:PORT:TO 2
SENS:CORR:FRES:USER:SLIS2:PORT:FROM 1
SENS:CORR:FRES:USER:SLIS2:DATA:PHAS3?
The correction data from port 1 to port 2 is returned.
Usage: Query only
Manual operation: See "Selected File" on page 611
[SENSe:]CORRection:FRESponse:BASeband:USER:SLISt<sli>:INSert <FilePath>
[SENSe:]CORRection:FRESponse:INPut<ip>:USER:SLISt<sli>:INSert <FilePath>
[SENSe:]CORRection:FRESponse:USER:SLISt<sli>:INSert <FilePath>
Loads a new Touchstone file for the current configuration. The maximum number of
files per configuration is 15. The new file is added below the entry specified by the
<sli> index. All other entries with a higher suffix are moved down by one position.
To change the order of the files, use the [SENSe:]CORRection:FRESponse:USER:
SLISt<sli>:MOVE command.
To determine which files are available, use [SENSe:]CORRection:FRESponse:
USER:SLISt<sli>:CATalog? on page 1109.
Suffix:
<sli>
.
1..n
Index in Touchstone file list
Use [SENSe:]CORRection:FRESponse:USER:
SLISt<sli>:SIZE? to determine the maximum index number.
Parameters:
<FilePath> string
Path and file name
The file extension of the Touchstone file must correspond to the
number of ports included in the file. For example, a file contain-
ing 4 parameters for S11, S22, S12 and S21 must have the
extension .s2p.
The default directory for Touchstone files is
C:\R_S\INSTR\USER\Fresponse.
Manual operation: See "Add Touchstone File" on page 610
Configuring the R&S FSV/A
