R&S FSV3000 Series - Page 610

General Instrument Setup
R&S
®
FSVA3000/ R&S
®
FSV3000
610User Manual 1178.8520.02 ─ 01
Remote command:
[SENSe:]CORRection:FRESponse:USER:SLISt<sli>:PORTs:TO on page 1112
[SENSe:]CORRection:FRESponse:USER:SLISt<sli>:PORTs:FROM
on page 1111
Add Touchstone File
Loads a new Touchstone file for the current configuration. The maximum number of
files per configuration is 15. The new file is added below the currently selected file. To
change the order of the files, use the Move File Up or Down icons.
The file extension of the Touchstone file must correspond to the number of ports inclu-
ded in the file. For example, a file containing 4 parameters for S11, S22, S12 and S21
must have the extension .s2p.
The default directory for Touchstone files is C:\R_S\INSTR\USER\Fresponse.
Remote command:
[SENSe:]CORRection:FRESponse:USER:SLISt<sli>:INSert on page 1110
Remove File
Removes the selected Touchstone file from the current configuration.
Remote command:
[SENSe:]CORRection:FRESponse:USER:SLISt<sli>:REMove on page 1112
[SENSe:]CORRection:FRESponse:USER:SLISt<sli>:CLEar on page 1109
Move File Up or Down
Moves the selected Touchstone file one position up or down in the list of files, changing
the order in which the correction data is applied.
Remote command:
[SENSe:]CORRection:FRESponse:USER:SLISt<sli>:MOVE on page 1111
Frequency Response active
Activates or deactivates the use of additional frequency response (.fres) files. The
correction data is these files is applied after any correction settings in active Touch-
stone files. Only active files are included in filter calculation.
Remote command:
[SENSe:]CORRection:FRESponse:USER:FSTate on page 1107
Frequency Response File Information
Provides information on loaded frequency response files and the order of their applica-
tion.
ID ← Frequency Response File Information
Consecutive number which determines the order in which the correction files are
applied to the measurement data. The maximum number of files per configuration is
15.
An LED-like symbol indicates whether the file and frequency response in general is
active (symbol "lights up") or not (symbol is dark). A green symbol represents a fre-
quency response (.fres) file.
Frequency Response Correction (R&S
FSV/A-K544)
