Remote commands exclusive to customize the display colors and themes
DISPlay:CMAP<it>:DEFault<ci>.................................................................................... 1120
DISPlay:CMAP<it>:HSL................................................................................................1120
DISPlay:CMAP<it>:PDEFined....................................................................................... 1121
DISPlay:THEMe:CATalog?............................................................................................ 1121
DISPlay:THEMe:SELect................................................................................................1121
DISPlay:CMAP<it>:DEFault<ci>
This command resets the color scheme for the display. The query returns the default
color scheme.
Suffix:
<it>
.
Selects the item for which the color scheme is to be defined.
<ci> 1
Current colors with a white background and a black grid.
2
Optimized colors.
3
Customized colors.
4
Current screen colors (setting for hardcopies).
Suffix irrelevant for query
Return values:
<DefScheme> 1 | 2 | 3 | 4
The default color scheme for the selected item, as specified by
the <ci> suffix.
Example:
DISP:CMAP:DEF2
Selects default setting 2 for setting the colors.
DISP:CMAP:DEF?
//Result: 2
Manual operation: See " Screen Colors " on page 573
DISPlay:CMAP<it>:HSL <hue>, <sat>, <lum>
This command selects the color for various screen elements in the display.
Suffix:
<it>
.
1..n
Selects the item for which the color scheme is to be defined.
Parameters:
<hue> tint
Range: 0 to 1
<sat> saturation
Range: 0 to 1
