Storing and Recalling Limit Lines
Limit lines can be stored with the configuration settings so they can be recalled for
other measurements at a later time (seeChapter 11.3, "Storing and Recalling Instru-
ment Settings and Measurement Data", on page 531). Note, however, that any
changes made to the limit lines after storing the configuration file cannot be restored
and will be overwritten by the stored values when the configuration file is recalled.
Always remember to store the settings again after changing the limit line values.
After recalling measurement settings, the limit line values applied to the measurement
may be different to those displayed in the "Limit Lines" dialog box; see "Saving and
recalling transducer and limit line settings" on page 532.
9.4.2.2 Limit Line Settings and Functions
Access: "Overview" > "Analysis" > "Lines"
or: [LINES] > "Line Config"
Up to 8 limit lines can be displayed simultaneously in the R&S FSV/A. Many more can
be stored on the instrument.
Stored limit line settings
When storing and recalling limit line settings, consider the information provided in "Sav-
ing and recalling transducer and limit line settings" on page 532.
● Limit Line Management.........................................................................................474
● Limit Line Details...................................................................................................477
Limit Line Management
Access: "Overview" > "Analysis" > "Lines" > "Limit Lines"
or: [LINES] > "Line Config" > "Limit Lines"
