Common Analysis and Display Functions
R&S
®
FSVA3000/ R&S
®
FSV3000
496User Manual 1178.8520.02 ─ 01
Function Trace Settings
Preset All Traces Trace 1: Clear Write
Auto Detector (Auto Peak)
Traces 2-6: Blank
Auto Detector
Set Trace Mode
Max | Avg | Min
Trace 1: Max Hold
Auto Detector (Positive Peak)
Trace 2: Average
Auto Detector (Sample)
Trace 3: Min Hold
Auto Detector (Negative Peak)
Traces 4-6: Blank
Auto Detector
Set Trace Mode
Max | ClrWrite | Min
Trace 1: Max Hold
Auto Detector (Positive Peak)
Trace 2: Clear Write
Auto Detector (Auto Peak)
Trace 3: Min Hold
Auto Detector (Negative Peak)
Traces 4-6: Blank
Auto Detector
Remote command:
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<undef>:PRESet on page 961
Trace 1 / Trace 2 / Trace 3 / Trace 4 (Softkeys)
Displays the "Traces" settings and focuses the "Mode" list for the selected trace.
For details see Chapter 9.5.1.3, "How to Configure a Standard Trace", on page 497.
Remote command:
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<t>[:STATe] on page 961
Copy Trace
Access: "Overview" > "Analysis" > "Traces" > "Copy Trace"
Copies trace data to another trace.
The first group of buttons (labeled "Trace 1" to "Trace 6" ) selects the source trace. The
second group of buttons (labeled "Copy to Trace 1" to "Copy to Tace 6" ) selects the
destination.
Remote command:
TRACe<n>:COPY on page 965
Trace Configuration
