CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:ACLR[:RELative] <Limit>[,
<UpperLimit>]
This command defines the relative limit for the ACLR power in the specified gap chan-
nel. The reference value for the relative limit is the measured channel power.
If you have defined an absolute limit as well as a relative limit, the R&S FSV/A uses the
lower value for the limit check.
Suffix:
<n>
.
irrelevant
<li> irrelevant
<gap> Gap channel number
Parameters:
<Limit> Defines the relative limit for the ACLR power in the specified gap
channel in dB.
Default unit: DB
<UpperLimit> Ignored.
Default unit: DB
Example:
CALC:LIM:ACP:GAP1:ACLR:REL 3dB
Manual operation: See " Limit Checking " on page 180
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:ACLR[:RELative]:STATe <State>
This command turns the relative limit check for the specified gap (CACLR) channel on
and off.
You have to activate the general ACLR limit check before using this command with
CALCulate<n>:LIMit<li>:ACPower[:STATe].
Suffix:
<n>
.
irrelevant
<li> irrelevant
<gap> 1..n
Gap (CACLR) channel number
Parameters:
<State> ON | OFF | 1 | 0
*RST: 0
Example:
CALC:LIM:ACP:GAP1:REL:STAT ON
Manual operation: See " Limit Checking " on page 180
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>[:CACLr][:RELative] <Limit>,
<UpperLimit>
This command defines the relative limit of the specified gap (CACLR) channel. The ref-
erence value for the relative limit is the measured channel power.
