Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
782User Manual 1178.8520.02 ─ 01
Remote commands exclusive to channel power measurements
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:ACLR:RESult?............................................782
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>[:CACLr]:RESult?......................................... 782
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:RESult:PHZ....................................... 783
[SENSe:]POWer:ACHannel:MODE..................................................................................784
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:ACLR:RESult?
The command returns the ACLR power limit check results for the selected gap channel
in an MSR ACLR measurement.
To get a valid result, you have to perform a complete measurement with synchroniza-
tion to the end of the measurement before reading out the result. This is only possible
for single sweep mode.
See also INITiate<n>:CONTinuous on page 746.
Suffix:
<n>
.
1..n
<li> 1..n
irrelevant
<gap> 1..n
Gap (CACLR) channel number
Return values:
<LowerGap_AB>
<UpperGap_AB>
<LowerGap_BC>
<UpperGap_BC>
<LowerGap_CD>
<UpperGap_CD>
<LowerGap_DE>
<UpperGap_DE>
Example:
INIT:IMM;*WAI;
CALC:LIM:ACP:GAP2:ACLR:RES?
PASSED,PASSED
Usage: Query only
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>[:CACLr]:RESult?
The command returns the limit check results for the upper and lower gap (CACLR)
channels for the selected gap in an MSR ACLR measurement.
To get a valid result, you have to perform a complete measurement with synchroniza-
tion to the end of the measurement before reading out the result. This is only possible
for single sweep mode.
