Remote Commands
R&S
®
FSVA3000/ R&S
®
FSV3000
949User Manual 1178.8520.02 ─ 01
UNIT<n>:PMETer<p>:POWer:RATio <Unit>
This command selects the unit for relative power sensor measurements.
Suffix:
<n>
.
irrelevant
<p> Power sensor index
Parameters:
<Unit> DB | PCT
*RST: DB
Example:
UNIT:PMET:POW:RAT DB
Manual operation: See " Unit/Scale " on page 320
Triggering with Power Sensors
[SENSe:]PMETer<p>:TRIGger:DTIMe..............................................................................949
[SENSe:]PMETer<p>:TRIGger:HOLDoff...........................................................................949
[SENSe:]PMETer<p>:TRIGger:HYSTeresis.......................................................................950
[SENSe:]PMETer<p>:TRIGger:LEVel............................................................................... 950
[SENSe:]PMETer<p>:TRIGger:SLOPe............................................................................. 951
[SENSe:]PMETer<p>:TRIGger[:STATe].............................................................................951
[SENSe:]PMETer<p>:TRIGger:DTIMe <Time>
This command defines the time period that the input signal has to stay below the IF
power trigger level before the measurement starts.
Suffix:
<p>
.
Power sensor index
Parameters:
<Time> Range: 0 s to 1 s
Increment: 100 ns
*RST: 100 µs
Default unit: S
Example:
PMET2:TRIG:DTIMe 0.001
[SENSe:]PMETer<p>:TRIGger:HOLDoff <Holdoff>
This command defines the trigger holdoff for external power triggers.
Suffix:
<p>
.
Power sensor index
Setting Basic Measurement Parameters
