Instrument Function
R&S
®
SMB100A
180Operating Manual 1407.0806.32 ─ 21
Remote command:
[:SOURce<hw>]:SWEep[:FREQuency]:SHAPe on page 422
Retrace - RF Frequency Sweep
Activates that the signal changes to the start frequency value while it is waiting for the
next trigger event.
You can enable this feature, when you are working with sawtooth shapes in sweep
mode "Single" or "External Single", see Mode - RF Frequency Sweep.
Remote command:
[:SOURce<hw>]:SWEep[:FREQuency]:RETRace on page 422
Step Lin/Log - Frequency Sweep
Sets the step width for the individual frequency sweep steps.
At each step this value is added to the current frequency.
Depending on the Spacing - Frequency Sweep mode you have set, the corresponding
parameter is displayed.
"Step Lin"
The step width is a constant value in Hz.
Remote command:
[:SOURce<hw>]:SWEep[:FREQuency]:STEP[:LINear] on page 423
RF Block
