Instrument Function
R&S
®
SMB100A
195Operating Manual 1407.0806.32 ─ 21
Select Destination / Source - List Mode
Calls the "File Manager" for selecting the list mode list to be exported (source) into an
ASCII file or the destination for the ASCII file to be imported (destination) in.
Remote command:
[:SOURce<hw>]:LIST:DEXChange:SELect on page 364
Import / Export - List Mode
Starts the export or import of the selected file.
When import is selected, the ASCII file is imported as list mode list.
When export is selected, the list mode list is exported into the selected ASCII file.
Remote command:
[:SOURce<hw>]:LIST:DEXChange:EXECute on page 363
Filling the List Mode Data automatically
The "Fill List Mode Data" menu enables you to automatically set the values in the List
Mode table.
The start line and the number of rows to be filled are defined under "From" and
"Range".
The column to be filled is selected under "Select column to fill". Depending on the
selection here, the default for start, end, and increment value are set. As the settings
are interdependent, a change of one parameter may result in the automatic change of
one or more of the other parameters.
The filling of the column with the selected value settings is started with button "Fill".
The list entries are only computed when the "Fill" button is pressed.
From
Sets the start value of the index range.
Remote command:
n.a.
Range
Sets the range for filling the table.
RF Block
