Remote Control Commands

R&S

SMB100A

365Operating Manual 1407.0806.32 ─ 21

Example:

LIST:DEXC:MODE IMP

selects that ASCII files with frequency and level value pairs are

imported and transferred into list mode lists.

LIST:DEXC:AFIL:SEL ‘/var/list.csv'

selects that ASCII file list.csv is imported.

LIST:DEXC:SEL ‘/var/list_imp'

selects that the ASCII file list.csv is imported into list mode

list list_imp.

Manual operation: See "Select Destination / Source - List Mode" on page 195

[:SOURce<hw>]:LIST:DWELl

<Dwell>

Sets the dwell time. The R&S SMB generates the signal with the frequency / power

value pairs of each list entry for that particular period.

Parameters:

<Dwell> float

Range: 7E-4 to 100

Increment: 1E-4

*RST: 15E-3

Example:

LIST:DWEL 15

each setting in the list is retained for 15 ms.

Manual operation: See "Dwell Time - List Mode" on page 190

[:SOURce<hw>]:LIST:FREE?

Queries on the free storage space for list mode lists.

Return values:

<Free> integer

Range: 0 to INT_MAX

*RST: 0

Example:

LIST:FREE?

Usage: Query only

Response: 2147483647;1

[:SOURce<hw>]:LIST:FREQuency <Frequency>

Fills the FREQuency column of the selected list with data.

*RST does not affect data lists.

SOURce Subsystem
