Ricoh D065 - Fax Unit Configuration

Fax Unit Configuration
D418 192 SM
6.5 FAX UNIT CONFIGURATION
Component Code No. Remarks
FCU 2
MBU 1
Speaker Assembly 5
Interface Board (IF-A) 3
Interface Board (IF3)
D418-01
4
Included with fax option unit
CCU I/F Board 7
G3 Board
D418-05
9
Included with optional G3 interface unit.
G3 Board D418-05 8 Included with optional G3 interface unit.
Expansion Memory B447 6 Common with R-C4/4.5
Handset Type 1018 B433 - USA only. Common with R-C4/4.5
