Ricoh D065 - Accessories; Gigabit Ethernet Type B (D377); Installation

MFP Options
D062/D063/D065/D066 2-130 SM
2.20.14 GIGABIT ETHERNET TYPE B (D377)
Accessories
Description Q'ty
1. Gigabit Ethernet 1
2. Ferrite Core 1
3. Screw 2
4. Cap for Network Slot 1
Installation
1. Switch the machine off.
2. Remove the controller box cover (
p.4-105 "CNT Board (Controller Board)").
3. Remove the Gigabit Ethernet slot cover [A] (
x 1).
Rev. 06/15/2011
