Replacement and Adjustment
D454 4 SM
1.1.6 INNER LOWER COVER
1. Open the front cover.
2. Inner lower cover [A] ( x 1, hook)
1.1.7 REAR UPPER COVER
1. Rear upper cover [A] (
x 4)
1.1.8 REAR LOWER COVER
1. Rear upper cover ( p.4)
