Ricoh D065 - Dynamic Roller Transport Motor; Registration Roller Release Motor

Replacement and Adjustment
D454 12 SM
1.2.8 DYNAMIC ROLLER TRANSPORT MOTOR
1. Rear upper cover ( p.4)
2. Dynamic roller transport motor bracket [A](
x 1, x 2)
3. Dynamic roller transport motor (
x 2)
1.2.9 REGISTRATION ROLLER RELEASE MOTOR
1. Rear upper cover ( p.4)
2. Rear lower cover (
p.4)
