Copy Connector Kit (B328)
SM 2-99 D062/D063/D065/D066
Installation
2.18 COPY CONNECTOR KIT (B328)
2.18.1 ACCESSORIES
Description Q’ty
1. Copy Connector Board B328 2
2. Power Repeater Cable 2
3. Coupling Interface Cable 1394 3
4. Repeater Hub 1394 2
5. Ferrite Core 2
6. Keytop for B234 (Not used) 4
7 Keytop 4
8 Keytop for B132 (Not used) 8
2.18.2 PREPARATION
Before you begin the installation procedure:
 Measure the distance between the machines to be connected.
 Confirm that the printer/scanner option is installed on the machines.
Rev. 08/03/2009
