Ricoh D065 - Rear Fence Hp Sensor Replacement; Tandem Right Tray Paper Sensor Replacement

Paper Feed
SM 4-85 D062/D063/D065/D066
Replacement
and
Adjustment
4.11.3 REAR FENCE HP SENSOR REPLACEMENT
1. Turn off the machine.
2. Pull out the tandem feed tray.
3. Rear bottom plate [A] (
x 1).
4. Back fence transport gear [B] (
x 1)
5. Move the back fence [C] to the right.
6. Rear HP sensor [D] (
x 1)
4.11.4 TANDEM RIGHT TRAY PAPER SENSOR
REPLACEMENT
1. Turn off the machine.
2. Remove the right tandem tray (
p.4-82)
3. Inner cover [A] (
x 2)
4. Side fences [B] (
x 1 each)
