Ricoh D065 - Fusing Unit Thermistors and Thermostats

Fusing Unit
D062/D063/D065/D066 4-58 SM
5. Open the exit separation pawl assembly [C].
6. Stopper bracket [D] (
x 1)
7. Fusing unit [E] (
x 2, x 2)
 Support the bottom of the fusing unit with your hand as you remove it.
4.9.2 FUSING UNIT THERMISTORS AND THERMOSTATS
 Remove the fusing unit (
p.4-57)
1. Upper cover [A] (
x 1)
2. Press in on the internal pawls [B] to release them then remove them.
 Make sure that the pawls [B] engage correctly when you reinstall the unit.
