Main Machine
D062/D063/D065/D066 2-16 SM
Tandem Tray
Before shipping the machine, the tandem tray is set for A4 or LT LEF and must be adjusted
if the customer wants to use the tandem tray for another paper size.
Feed Station Allowed Size
Tandem Tray (Tray 1) A4 LEF, LT LEF
1. Open the front cover.
2. Completely pull out the tandem feed tray [A] so that the right tandem tray [B] separates
from the left tandem tray.
3. Remove the right tandem inner cover [A].
4. Re-position the side fences [B] (
x 2). The outer slot position is used when loading
A4 size paper.
5. Re-install the right tandem inner cover [A].
To Next Page
