Fax Communication Features
SM 175 D418
Fax Option
Type 9001
D418
5.4 FAX COMMUNICATION FEATURES
5.4.1 MULTI-PORT
When the optional extra G3 Interface Unit is installed, communication can take place at the
same time through the two or three lines at once.
Option Available Line Type
Available protocol
Combinations
Standard only PSTN G3
Extra G3 Interface Unit (single) PSTN + PSTN G3 + G3
Extra G3 Interface Unit
(double)
PSTN + PSTN +PSTN G3 + G3 +G3
5.4.2 DOCUMENT SERVER
The base copier's scanner scans the original at the selected resolution. The IPU video
processes the data and transfers it to the controller board.
Then the controller stores the data in the page memory for the copier function, and
