MFP Options
D062/D063/D065/D066 2-114 SM
8. Attach ANT2 [D] to the right rear corner.
9. Route the cables and use the clamps to attach them as shown.
SP Mode Settings for 802.11a/g Wireless LAN
The following SP commands can be set for 802.11a/g
1. Go into the SP mode
2. Touch "Copy SP" on the touch-panel to open the SP command selection screen.
3. Do SP5840-11.
SP No. Name Function
5840 011 WEP Key Select Used to select the WEP key (Default: 00).
2.20.6 BLUETOOTH INTERFACE UNIT TYPE C (B826)
Accessories
Check the quantity and condition of the accessories.
No. Description Q'ty
1 Bluetooth card 1
2 Bluetooth card cover 1
3 Bluetooth board 1
4 Bluetooth card adapter 1
Rev. 08/03/2009
