Ricoh D065 - General; Multi-Folding Unit Fd5000 (D454)

Optional Equipment
SM Appendix 1-21 D062/D063/D065/D066
Appendix:
General
Specifications
Paper Weight
64 g/m
2
-216 g/m
2
17 lb. Bond- 80 lb. b Cover
Original Set Position Center
Normal Feed Face-up
Original Set
Booklet Feed Face-down
1.2.12 MULTI-FOLDING UNIT FD5000 (D454)
General
Dimensions (W × D × H) 470 × 980 × 730 mm (18.6 × 38.6 × 28.8 in.)
Weight Approx. 92 kg (202.9 lb.)
Power Consumption Maximum 270 W (A separate power source is required.)
Power Source 220 - 240 V, 50/60 Hz, 1.2 A
Operating Environment
Temperature and humidity ranges: Same as main
machine.
Paper Weight
Single sheet mode:
64 to 103 g/m
2
(17 lb. Bond - 28 lb. Bond)
Multiple sheets mode:
64 to 80 g/m
2
(17 lb. Bond - 20 lb. Bond)
Folding Methods 6 (see below)
Speed Straight-Through 100 to 700 mm/s
Folding 270 to 700 mm/s
Straight-Through Feed Size Postcard to 13x19.2"
Type
Used paper: A3, A4, B4, B5
OHP: A4, B5
Tap paper: A4 LEF, LT LEF
Folding Methods 6 (FM1 to FM6)
