Replacement and Adjustment
D454 82 SM
L1 L2 L3 S1 S2 S3
FM1 ---
F Long F Long
---
Lower F Raise F
---
F Short F Short
---
Raise F Lower F
FM2
F Long
--- ---
Raise F
--- ---
F Short
--- ---
Lower F
--- ---
FM3
F Long F Long
---
Raise F Lower F
---
F Short F Short
---
Lower F Raise F
---
FM4
F Long F Long
---
Raise F Lower F
---
F Short F Short
---
Lower F Raise F
---
FM5
F Long F Long
---
Raise F Lower F
---
F Short F Short
---
Lower F Raise F
---
FM6
F Long F Long F Long Lower F Lower F Raise F
F Short F Short F Short Raise F Raise F Lower F
Table Key
You must refer to the "Skew Correction Reference Diagrams". The following abbreviations
are used in the table above.
Term What It Means
F Long Front measurement of L1, L2, or L3 is longer than Rear..
F Short Front measurement of L1, L2, or L3 is shorter than Rear..
S1, S2, S3
Refers to Stopper 1, Stopper 2, Stopper. In the diagrams these are
annotated as: {, , } respectively.
Raise F
Raise the front end of the stopper fence. For more, see below.
Lower F
Lower the front end of the stopper fence. For more, see below.
