D454 124 SM
2.5.10 FOLD MOTORS, SENSORS, SOLENOIDS
1. Stopper 2 Motor 8. Stopper 1 HP Sensor
2. Stopper 2 HP Sensor 9. Stopper 3 Paper Sensor
3. Jogger Fence Motor 10. Stopper 3 HP Sensor
4. Stopper 2 Paper Sensor 11. Stopper 3 Motor
5. Stopper 1 Paper Sensor 12. Positioning Roller Motor
6. Positioning Roller HP Sensor 13. Direct Send JG Motor
7. Stopper 1 Motor 14. LE Stop Pawl Solenoid
