Service Call Conditions
SM Appendix 3-41 D062/D063/D065/D066
Appendix:
Service Call
Conditions
4. Booklet finisher main board defective
Stack Plate Motor Error 2: Center Motor (B830)
747 D
The stack plate HP sensor (center) does not activate within 500 ms after the
motor turns on. The 1st detection failure causes a jam error, and the 2nd
failure causes this SC code.
If the motor is operating
1. Center stack plate HP sensor harness loose, broken, defective
2. Center stack plate HP sensor defective
If the motor is not operating:
1. Motor blocked by an obstruction
2. Motor harness loose, broken, defective
3. Motor defective
4. Booklet finisher main board defective
Stack Plate Motor Error 3: Rear Motor (B830)
748 D
The stack plate HP sensor (rear) does not activate within 500 ms after the
motor turns on. The 1st detection failure causes a jam error, and the 2nd
failure causes this SC code.
If the motor is operating
1. Rear stack plate HP sensor harness loose, broken, defective
2. Rear stack plate HP sensor defective
If the motor is not operating:
1. Motor blocked by an obstruction
2. Motor harness loose, broken, defective
3. Motor defective
4. Booklet finisher main board defective
