Service Call Conditions
SM Appendix 3-51 D062/D063/D065/D066
Appendix:
Service Call
Conditions
Positioning Roller Motor Error Multi Folder (D454)
The positioning roller HP sensor did not detect the positioning roller in
(or out of) its home position within the prescribed time. The 1st
occurrence causes a jam, and the 2nd occurrence causes this SC
code.
783-12 B
 Positioning roller HP sensor dirty
 Sensor harness or connector loose, broken, defective
 Positioning roller motor harness or connector loose, broken,
defective
 Sensor defective
 Motor or motor drive board defective
FM2 Direct-Send JG Motor Multi Folder (D454)
The direct-send JG HP sensor did not detect the direct-send JG in (or
out of) its home position within the prescribed time. The 1st occurrence
causes a jam, and the 2nd occurrence causes this SC code.
783-13 B
 FM2 direct-send JG HP sensor dirty
 Sensor harness or connector loose, broken, defective
 FM2 direct-send JG motor harness or connector loose, broken,
defective
 Sensor defective
 Motor or motor drive board defective
FM6 Pawl Motor Multi Folder (D454)
The FM6 pawl HP sensor did not detect the FM6 pawl in (or out of) its
home position. The 1st occurrence causes a jam, and the 2nd
occurrence causes this SC code.
783-14 B
 FM6 pawl HP sensor dirty
 Sensor harness or connector loose, broken, defective
 FM6 pawl motor harness or connector loose, broken, defective
