Service Program Mode Tables
D062/D063/D065/D066 4-2 SM Appendix
1002* Side-to-Side Registration
Adjusts printing side-to-side registration for each feed station, using test pattern
(SP2902-003, No.18).
These SP's should be adjusted after replacing the laser synchronization detector
or the laser optical unit.
001 Tray-1
002 Tray-2
003 Tray-3
004 Tray-4 (Japan Only)
005 By-pass Tray
006 LCT
007 Duplex Tray
[–9 to +9/0/0.1 mm]
1003 Registration Buckle Adjustment
Adjusts the registration motor timing. This timing determines the amount of
paper buckle at registration. (A higher setting causes more buckling.)
[–9 to +9/0/1 mm]
001* Tray LCT
002 Duplex Tray
003* By-pass Tray
1007 By-pass Feed Paper Size Display
-001
Use this SP to confirm the size of the paper detected in the by-pass tray if paper
is skewing during feeding.
1008* Duplex Fence Adjustment
