Service Program Mode Tables
D062/D063/D065/D066 4-14 SM Appendix
Start/End
006
LD1 Adjustment
Start/End
007
LD2 Adjustment
Start/End
008
LD3 Adjustment
Start/End
the adjustments performed for SP2103 001-004.
[0 to 1/0/1]
0: LD beam OFF
1: LD beam ON
2104* Small Pitch Banding Reduction
001 Reduction Mode On/Off Setting:1200 dpi
Switches on/off the setting that corrects uneven images generated during 1200
dpi printing.
[0 to 1/1]
1: On
0: Off
Unevenness may appear in dot patterns or narrowly spaced horizontal lines, i.e.
some areas may appear lighter or darker than others.
002 Reduction Mode On: 1200 dpi Printing
Adjusts the amount of correction for uneven images generated during 1200 dpi
printing.
[–20 to +10/-8/1]
003 Reduction Mode On/Off: 1200 dpi Copying
Switches on/off the setting that corrects uneven images generated during 1200
dpi copying.
[0 to 1/1]
1: On
0: Off
004 Reduction Mode On: 1200 dpi Copying
Adjusts the amount of correction of uneven image generated during 1200 dpi
