Ricoh D065 - Page 588

Service Program Mode Tables
SM Appendix 4-55 D062/D063/D065/D066
Appendix:
Service
Program
Mode Tables
001 Displays the reference voltage for Green adjusted by gray balance adjustment.
4611
Gray Balance Adj Value: B DFU
001 Displays the reference voltage for Blue adjusted by gray balance adjustment.
4615
Gray Balance Adj Value: R (Factory Setting) DFU
001 Displays the reference voltage for Red adjusted at factory.
4616
Gray Balance Adj Value: G (Factory Setting) DFU
001 Displays the reference voltage for Green adjusted at factory.
4617
Gray Balance Adj Value: B (Factory Setting) DFU
001 Displays the reference voltage for Blue adjusted at factory.
4628
Gain Range Adj Value: R DFU
001 R FC:F:R
003 R FC:L:R
005 R BK:F:R
007 R BK:L:R
4629
Gain Range Adj Value: G DFU
001 R FC:F:G
003 R FC:L:G
005 R BK:F:G
007 R BK:L:G
4630
Gain Range Adj Value: B DFU
001 R FC:F:B
