Ricoh D065 - Page 607

Service Program Mode Tables
D062/D063/D065/D066 4-74 SM Appendix
001 Executes the homing movement of the caridge unit.
FL Correction ON/OFF
4806*
Turns on or off the FL correction for each color..
[0 or 1 / 0 / 1]
0: OFF, 1: ON
001 RED
002 GREEN
003 BLUE
Result FL Detection
4808
Displays the each data of the FL correction.
[0 to 1023 / - / 1]
001
to
020
FR1 to FR20
021
to
040
LR1 to LR20
041
to
060
FG1 to FG20
061
to
080
LG1 to LG20
081
to
100
FB1 to FB20
