Input/Output Check
D062/D063/D065/D066 4-268 SM Appendix
011 Dynamic roller Lift Motor
012 Registration Roller Release Motor
013 Fold Plate Motor
014 Jogger Fence Motor
015 Positioning Roller Motor
016 Direct-Send JG Motor
017 FM6 Pawl Motor
018 1st Fold Motor
019 2nd Fold Motor
020 Crease Motor
021 Bypass JG Solenoid
022 Exit JG Solenoid
023 Top Tray JG Solenoid
024 LE Stop Pawl Solenoid
025 Reverse JG Solenoid
Turn on the electrical
components of the finisher
individually for test purposes.
To Next Page
