Ricoh K-C3 - Relay Sensor; Lower Paper Feed Clutch (Two-Tray Models Only)

B245/B276/B277/B268/B269 Service Manual 18-Jan-06
91
Relay Sensor
1. Relay clutch (
Previous procedure)
2. Sensor bracket [A] (
x 1)
3. Relay sensor [B] (
x 1)
Lower Paper Feed Clutch (Two-tray Models Only)
1. Rear lower cover (
p.54)
2. Clutch bracket [A] (
x 2)
3. Lower paper feed clutch [B] (
x 2, 1 bushing, x 1)
