Ricoh K-C3 - Paper Feed Section; Paper Feed Roller

B245/B276/B277/B268/B269 Service Manual 18-Jan-06
83
Paper Feed Section
Paper Feed Roller
1. Paper cassette
2. Clip [A]
3. Push the shaft back through the opening, and tilt it up.
 If the black plastic bushing [B] comes off, make sure you remount it when
reinstall the shaft.
4. Paper feed roller [C]
