B245/B276/B277/B268/B269 Service Manual 18-Jan-06
141
SP Mode Tables
The following codes are used:
Asterisk (*): The settings are saved in the NVRAM. Most of them return to the default
values when you execute SP 5801 2
The DFU menu is for design or factory use only. You must not change the settings.
Brackets ([ ]): The brackets enclose the setting rage, default value, and minimum step
(with unit) as follows: [Minimum Maximum / Default / Step].
SSP: The program is in the SSP Mode only. Consult your supervisor before you use this
program.
SP1-XXX (Feed)
Leading Edge Registration
1001*
Adjusts the printing leading-edge registration from paper trays.
1001 1 All Trays
1001 2 By-pass
1001 3 Duplex
[–9.0 ~ 9.0 / 0.0 / 0.1 mm/step] (
p.111)
Side-to-Side Registration
1002*
Adjusts the printing side-to-side registration from each paper feed station, using
the Trimming Area Pattern (SP 5902, No.10). Adjustments are supported for all
4 possible feed trays (including optional trays).
The SP 1002 1 setting is applied to all trays, not just the 1st tray. Settings for
trays 2 to 4 are offsets relative to the SP 1002 1 setting.
For duplex copies, the value for the front side is determined by SP 1002 1 to 4,
and the value for the rear side is determined by SP 1002 6.
1002 1 1st tray
1002 2 2nd tray
1002 3 3rd tray
1002 4 4th tray
1002 5 By-pass
1002 6 Duplex
[–9.0 ~ 9.0 / 0.0 / 0.1 mm/step] (
p.111)
