Ricoh K-C3 - Exit Sensor

B245/B276/B277/B268/B269 Service Manual 18-Jan-06
85
Exit Sensor
- Non-Duplex Models -
1. Open the right door.
2. Front right cover (
p.57)
3. Guide [A] (
x 2)
4. Exit sensor bracket [B] (
x 1)
5. Exit sensor [C] (
x 1)
- Duplex Models -
1. Open the right door.
2. Front right cover (
p.57)
3. Upper guide [D] (
x 2)
