B245/B276/B277/B268/B269 Service Manual 18-Jan-06
181
Num. Component
029 DF-Transport Motor
030 DF-Feed Motor
031 DF-Feed Clutch
032 DF-Pickup Solenoid
033 DF-Stamp Solenoid
034 DF-Gate Solenoid
035 1 bin Gate Solenoid
036 1 bin Tray Motor
037 1 bin Tray Motor Hold
038 Fusing Solenoid
040 Duplex Fan Motor High
041 Duplex Fan Motor Low
Serial Number Input (SP 5811)
- Specifying Characters -
SP 5811 1 specifies the serial number. For the basic machine (the machine without the
optional controller), you use the numeric keypad. For the GDI machine (the machine with the
optional controller), you use the numeric keypad and the optional operation panel.
A serial number consists of 11 characters. You can change each character by pressing one of
the first 11 keys on the numeric keypad (
, , , ... , , ).
For example, when you press the
key, the first character of the serial number changes as
follows:
0
1 2 ... 8 9 A B ... X Y Z.
When you press the
key, the second character changes likewise.
You can specify a digit ("0" to "9") or a capital letter ("A" to "Z") for the first four characters of
a serial number, and you can specify a digit in the other seven characters (not capital letters).
NVRAM Data Upload/Download (SP 5824/5825)
This procedure is for the basic machine only.
Make sure that you turn off the main switch before inserting or removing a flash
memory card. Installing or removing a flash memory card while the main switch is on
