Ricoh K-C3 - Image Processing; Image Processing Overview

B245/B276/B277/B268/B269 Service Manual 18-Jan-06
196
Board Structure
Block Diagram
Only B269/B277 models contain the duplex unit.
The one-bin tray is for models B268/B269 (with the optional controller box).
