Ricoh K-C3 - PCU Section; Pcu

B245/B276/B277/B268/B269 Service Manual 18-Jan-06
76
PCU Section
PCU
1. Toner bottle with the holder [A]
2. Open the right door.
3. Press the latch [B] and pull out the PCU [C].
 Do not touch the OPC drum surface with bare hands.
4. Load new developer (
p.80).
5. Do SP 2214 to reinitialize the TD sensor when you reassemble.
