B245/B276/B277/B268/B269 Service Manual 18-Jan-06
40
Key Counter Installation
 Unplug the machine power cord before starting the following procedure.
1. Remove the left cover.
2. Remove the rear cover.
3. Cut the cap [A] with nippers.
4. Punch out the small hole [B] using a screwdriver.
5. Hold the key counter plate nuts [C] on the inside of the key counter bracket [D]
and insert the key counter holder [E].
6. Secure the key counter holder to the bracket (
x 2).
7. Install the key counter cover [F] (
x 2).
