Ricoh K-C3 - Component Replacement Procedures; Exterior Covers & Operation Panel Procedures

B245/B276/B277/B268/B269 Service Manual 18-Jan-06
45
Installing Panels and Keys
1. Remove the dummy cover [A] from the operation panel
2. Install the printer/scanner panel [B] on the operation panel.
